Schneider Electric TM3TM3G Input/output analog module, Modicon TM3, 2 or temperature inputs, 1 output (spring) 24 VDC

Schneider Electric TM3TM3G Input/output analog module, Modicon TM3, 2 or temperature inputs, 1 output (spring) 24 VDC

Model: TM3TM3G

Supplier: Schneider Electric

Categories: PLC, PAC and Dedicated Controllers

After sales service. If you have any questions, click here.

PRODUCT DESCRIPTION

Schneider Electric TM3TM3G Input/output analog module, Modicon TM3, 2 or temperature inputs, 1 output (spring) 24 VDC

Analog input module4.JPG

Main

Range of product Modicon TM3

Product or component type Input/output analog module

Range compatibility Modicon M221

Modicon M241

Modicon M251

Modicon M262

Analogue input number 2

Analogue input type Current 4...20 mA

current 0...20 mA

voltage 0...10 V

voltage - 10...10 V

thermocouple - 200...1000 °C with thermocouple J

thermocouple - 200...1300 °C with thermocouple K

thermocouple 0...1760 °C with thermocouple R

thermocouple 0...1760 °C with thermocouple S

thermocouple 0...1820 °C with thermocouple B

thermocouple - 200...400 °C with thermocouple T

thermocouple - 200...1300 °C with thermocouple N

thermocouple - 200...800 °C with thermocouple E

thermocouple 0...2315 °C with thermocouple C

Ni 100/Ni 1000 temperature probe - 60...180 °C

Pt 100 temperature probe - 200...850 °C

Pt 1000 temperature probe - 200...600 °C

Analogue output number 1

Analogue output type Current: 4...20 mA

Current: 0...20 mA

Voltage: 0...10 V

Voltage: - 10...10 V

Complementary

Analogue input resolution 16 bits

15 bits + sign

Permissible continuous overload 13 V, analogue input type: voltage

40 mA, analogue input type: current

Input impedance <= 50 Ohm current

>= 1 MOhm voltage

>= 1 MOhm thermocouple

>= 1 MOhm temperature probe

Analogue output resolution 12 bits

LSB value 0.15 mV 0...10 Vvoltage

0.30 mV - 10...10 Vvoltage

0.30 µA 0...20 mAcurrent

0.244 µA 4...20 mAcurrent

0.1 °Ctemperature probe

0.1 °Cthermocouple

2.44 mV 0...10 V voltage

4.88 mV - 10...10 V voltage

4.88 µA 0...20 mA current

3.91 µA 4...20 mA current

Load type Resistive

Load impedance ohmic 1 kOhm voltage

300 Ohm current

Stabilisation time 1 ms

Conversion time 100 ms + 100 ms per channel + 1 controller cycle time for analogue input thermocouple

100 ms + 100 ms per channel + 1 controller cycle time for analogue input temperature probe

10 ms + 10 ms per channel + 1 controller cycle time for analogue input voltage/current

Sampling duration 10 ms, analogue input type: voltage/current

100 ms, analogue input type: voltage/current

100 ms, analogue input type: thermocouple

100 ms, analogue input type: temperature probe

Absolute accuracy error +/- 6 °C at 25 °C for thermocouple R, S 0...200 °C

+/- 0.4 % of full scale at 25 °C for thermocouple K - 200...0 °C

+/- 0.4 % of full scale at 25 °C for thermocouple J - 200...0 °C

+/- 0.4 % of full scale at 25 °C for thermocouple E - 200...0 °C

+/- 0.4 % of full scale at 25 °C for thermocouple T - 200...0 °C

+/- 0.4 % of full scale at 25 °C for thermocouple N - 200...0 °C

+/- 0.1 % of full scale at 25 °C for analogue input voltage/current

+/- 0.1 % of full scale at 25 °C for thermocouple C 0...2315 °C

+/- 0.1 % of full scale at 25 °C for Pt 100/Pt 1000, Ni 100/ Ni 1000 temperature probe

+/- 0.1 % of full scale at 25 °C for thermocouple R, S 200...1760 °C

+/- 0.1 % of full scale at 25 °C for thermocouple B 300...1820 °C

+/- 0.1 % of full scale at 25 °C for thermocouple K 0...1300 °C

+/- 0.1 % of full scale at 25 °C for thermocouple J 0...1000 °C

+/- 0.1 % of full scale at 25 °C for thermocouple E 0...800 °C

+/- 0.1 % of full scale at 25 °C for thermocouple T 0...400 °C

+/- 0.1 % of full scale at 25 °C for thermocouple N 0...1300 °C

+/- 0.1 % of full scale at 25 °C for analogue output voltage/current

temperature drift +/- 0.006 %FS/°C

Repeat accuracy +/-0.5 %FS for input

+/- 0.4 %FS for output

Non-linearity +/- 0.01 %FS, analogue output type: analog output

+/- 0.1 %FS, analogue input type: analog input

Output ripple 20 mV

Cross talk <= 1 LSB

[Us] rated supply voltage 24 V DC

Supply voltage limits 20.4…28.8 V

Type of cable Twisted shielded pairs cable <30 m for input/output circuit

Current consumption 55 mA at 24 V DC via external supply no load

55 mA at 5 V DC via bus connector no load

60 mA at 5 V DC via bus connector full load

80 mA at 24 V DC via external supply full load

Local signalling 1 LED (green) for PWR

Electrical connection 11 x 2.5 mm² removable spring terminal block with pitch 5.08 mm adjustment for inputs, outputs and supply

Insulation Between input and supply at 1500 V AC

Between input and internal logic at 500 V AC

Between output and supply at 1500 V AC

Between output and internal logic at 500 V AC

Marking CE

Surge withstand 1 kV power supply common mode conforming to EN/IEC 61000-4-5

0.5 kV power supply differential mode conforming to EN/IEC 61000-4-5

1 kV I/O common mode conforming to EN/IEC 61000-4-5

0.5 kV I/O differential mode conforming to EN/IEC 61000-4-5

Mounting support Top hat type TH35-15 rail conforming to IEC 60715

Top hat type TH35-7.5 rail conforming to IEC 60715

plate or panel with fixing kit

Height 90 mm

Depth 70 mm

Width 23.6 mm

Net weight 0.1 kg

Environment

Standards EN/IEC 61131-2

EN/IEC 61010-2-201

Resistance to electrostatic discharge 8 kV in air conforming to EN/IEC 61000-4-2

4 kV on contact conforming to EN/IEC 61000-4-2

Resistance to electromagnetic fields 10 V/m 80 MHz...1 GHz conforming to EN/IEC 61000-4-3

3 V/m 1.4 GHz...2 GHz conforming to EN/IEC 61000-4-3

1 V/m 2 GHz...3 GHz conforming to EN/IEC 61000-4-3

Resistance to magnetic fields 30 A/m conforming to EN/IEC 61000-4-8

Resistance to fast transients 1 kV (I/O) conforming to EN/IEC 61000-4-4

Resistance to conducted disturbances 10 V 0.15...80 MHz conforming to EN/IEC 61000-4-6

3 V spot frequency (2, 3, 4, 6.2, 8.2, 12.6, 16.5, 18.8, 22, 25 MHz) conforming to Marine specification (LR, ABS, DNV, GL)

Electromagnetic emission Radiated emissions - test level: 40 dBμV/m QP class A ( 10 m) at 30…230 MHz conforming to EN/IEC 55011

Radiated emissions - test level: 47 dBμV/m QP class A ( 10 m) at 230…1000 MHz conforming to EN/IEC 55011

Immunity to microbreaks 10 ms

Ambient air temperature for operation -10…55 °C horizontal installation

-10…35 °C vertical installation

Ambient air temperature for storage -25…70 °C

Relative humidity 10…95 %, without condensation (in operation)

10…95 %, without condensation (in storage)

IP degree of protection IP20

Pollution degree 2

Operating altitude 0...2000 m

Storage altitude 0…3000 m

Vibration resistance 3.5 mm at 5…8.4 Hz on DIN rail

3 gn at 8.4…150 Hz on DIN rail

Shock resistance 15 gn for 11 ms

Packing Units

Unit Type of Package 1 PCE

Number of Units in Package 1 1

Package 1 Height 7.62 cm

Package 1 Width 10.92 cm

Package 1 Length 13.46 cm

Package 1 Weight 200 g

Unit Type of Package 2 S02

Number of Units in Package 2 9

Package 2 Height 15 cm

Package 2 Width 30 cm

Package 2 Length 40 cm

Package 2 Weight 2.3 kg

Unit Type of Package 3 P06

Number of Units in Package 3 144

Package 3 Height 75 cm

Package 3 Width 40 cm

Package 3 Length 80 cm

Package 3 Weight 27.88 kg
