Pilz 787305 PNOZ X2.7P C 24VACDC 3n/o 1n/c Safety relay (standalone)
Electrical data
Supply voltage (V)24 V
Type of supply voltage U1AC/DC
Power consumption AC5.5 VA
Power consumption DC2.5 W
Inputs
Number of inputs2
Semiconductor outputs
Number of semicond. outputs0
Relay outputs
Utilisation cat. AC/DC1 stand.EN 60947-4-1
Voltage AC1 safety cont.240 V
Max. current AC1 safety cont.6 A
Voltage DC1 safety cont.24 V
Max. current DC1 safety cont.6 A
Utilisation cat. AC15/DC13sta.EN 60947-5-1
Voltage AC15 safety cont.230 V
Max. current AC15 safety cont.5 A
Voltage DC13 safety cont.24 V
Safety contacts: AC at UL240 VAC G.U. (same polarity)
Safety contacts: pilot dutyR300
Relay contact materialAgCuNi
Addit. contact details relay+ 0.2 µm Au
Environmental data
Climatic suitability to ...EN 60068-2-78
Ambient temperature-35 - 55 °C
Humidity rating93 % r. h. at 40 °C
Condensation permitted?Not permitted
EMC to standard ...EN 60947-5-1
EN 61000-6-2
EN 61000-6-4
EN 61326-3-1
Vibration to standard ...EN 60068-2-6
Clearance & creepage dist. toEN 60947-1
Overvoltage categoryIII / II
Pollution degree clear.&creep.2
Protection type, mounting
Protection type, housing
Terminal protection type
Mechanical data
Mounting positionany
Housing material lower section
Housing material front plateABS UL 94 V0
Housing material upper part
Connection terminalSpring-loaded terminal
Terminal styleplug-in
Height dimension101 mm
Width dimension22.5 mm
Depth dimension121 mm
Net weight185 g
Gross weight195 g
