Norgren B38-242-B1MA B38 Series stainless steel filter/regulator, 1/4 PTF, 0.4-10 bar

Applications include marine enviroments, oil and gas production, chemical and food processing, medical analysis

Designed for use in corrosive enviroments

Lloyd’s register type approval

Metallic parts meet NACE Standard MR-01-75

Relieving or non relieving models. Relieving models allow reduction of outlet pressure even when the system is dead-ended

Medium:Compressed Air

Port size:1/4" PTF

Maximum inlet pressure:20.0 bar

Operating temperature:-40 ... 80 °C

Outlet pressure adjustment:0.3 ... 9 bar

Gauge port:3/4" PTF

ATTRIBUTEVALUE

Medium:Compressed Air

Port size:1/4" PTF

Maximum inlet pressure:20.0 bar

Operating temperature:-40 ... 80 °C

Outlet pressure adjustment:0.3 ... 9 bar

Gauge port:3/4" PTF

Material - Adjusting knob:Stainless steel

Material - Body:Aluminium

Material - Bonnet:Aluminium

Material - Elastomers:Nitrile rubber

Material - Filter element:Sintered polypropylene

Range:B38

Similar model numbers:

B38-242-B1MA

B38-242-B1KA

B38-244-B2MA

B38-200-B2KA

B38-244-B1MA

B38-244-A1MA

B38-442-M1LA

B38-444-M2LA

B38-244-A1KA

B38-242-A2FA

B38-444-M1LA

B38-444-A1LA

B38-200-B1KA

B38-644-M1LA

B38-244-A2MA

B38-244-B1KA

B38-244-A2KA

B38-442-A1LA

B38-242-B2KA

B38-244-M1MA

B38-244-B2KA

B38-444-A2LA

B38-644-A1LA
